SIGNATURE LINE DDR5
Patriot’s Signature Line DDR5 memory modules are designed to deliver an immense performance improvement for next generation Intel platforms. Requiring only 1.1V of power, Signature DDR5 modules consume less power and emit less heat despite the increased frequency and speed. Enhanced power improvements include an onboard Power Management IC (PMIC), which provides better control of local voltage regulation while delivering increased threshold protection, simultaneous monitoring, intelligent voltage, and power management. The Signature Line DDR5 series includes onboard thermal sensors to monitor and protect against thermal issues and better overall reporting. In addition, the latest on-die ECC (Error-Correcting Code) further enhances the accuracy of data-processing and your overall system’s stability.
Patriot Signature Series DDR5 5600 MHz UDIMM Overview
Boost performance with the 16GB Signature Premium DDR5 5600 MHz UDIMM Memory Module from Patriot. Boasting a capacity of 16GB , this memory module delivers a 5600 MHz clock speed, 46-46-46-90 timings, and CL46 CAS latency for quick multitasking performance. Operating at 1.1V, it features a 288-pin connection and unbuffered memory with on-die error-correcting code (ECC) for reducing data errors. Plus, an aluminum heatshield ensures ample cooling. This memory module is RoHS compliant.
In the Box
- Patriot 16GB Signature Premium DDR5 4800 MHz UDIMM Memory Module
- Limited Lifetime Warranty
Patriot Signature Series DDR5 5600 MHz UDIMM Specs
| Capacity |
16 GB
|
| Kit Configuration |
1 x 16 GB
|
| Speed |
PC5-44800 (5600 MHz)
|
| Memory Type |
DDR5
|
| DIMM Type |
288-Pin DIMM
|
| Buffered/Registered |
No
|
| Error Correction (ECC) |
Non-ECC
|
| Voltage |
1.1 V
|
| CAS Latency |
CL46
|
| Heat Spreader |
Yes
|
| Built-in LED |
No
|
| Color |
Black
|
| Performance Profile |
No
|
| Height |
1.5″ / 37 mm
|
| Package Weight |
0.095 kg
|
| Box Dimensions (LxWxH) |
5.95 x 2.2 x 0.6″
|
